Actech Hc1 Drive Manual 5,0/5 3011 reviews
- Actech Hc1 Drive Manual Instructions
When the fault condition disappears or is cleared, the drive can be configured to automatically restart, it is the responsibility of the user and/or OEM and/or integrator to ensure that the drive is configured for safe operation. All safety information given in these Operating Instructions has the same layout: Signal Word! 3.7kW 220V TECORP HC1-A VFD AC Motor Drive HC1A03D723B. Carrier Frequency adjustable to 16KHz. Built-in PID control. Built-in simple PLC function. Built-in RS-232/485 communication interface. Low noise operation. Time(0.1-6500 Sec) adjustable. HC1-A Operation and Maintenance Manual. AC Technology Corporation. Home Products Lenze Americas User Manuals. AC Technology Corporation is a USA based company specializing in the. AC Tech Drives is. This manual covers the Lenze AC Tech SCF Series Variable Frequency. The drive must not be used as a safety device for machines.
Actech Hc1 Drive Manual Instructions
Contents 1. Introduction 1 1.1 Confirmations upon delivery 2 1.2 Nameplate information 2 2. Safety Precautions 2 2.1 Before delivery of current 2 2.2 In delivery of current 4 2.3 In running 4 3. Inverter standard specifications 4 3.1 Individual specifications 4 3.2 Common specifications 6 4. Storage & Installation 7 4.1 Storage 7 4.2 Location 7 4.3 Position 8 5. Wiring 9 5.1 Main circuit schematic diagram 9 5.2 Terminals 10 5.3 Standard Connection Diagram 12 5.4 Wiring Precautions 13 6. Using the digital operator 15 6.1 Explanations of the digital operator 15 6.2 Display data 17 6.3 Instructions of the digital operator 18 7. Trial Operation 19 7.1 Inspection before operation 19 7.2 Trial operation procedures 19 8. Function List 20 9. Explanations of the functions 27 10. Maintenance,Inspection&Trouble shooting 72 10.1 Precautions about maintenance and inspection 72 10.2 Regular Inspection items 72 10.3 Error information and its troubleshooting 74 10.4 Error and its analysis 75 11. Peripheral devices and specifications of options 77 11.1 Peripheral devices 77 11.2 Proper specifications of options 78 12. Appendices 81 12.1 Application demonstrations 81 This operation manual is 1.37 versions. Specifications are subject to change without notice for ongoing modifications and improvements. 1. Introduction Thank you for purchasing our high quality HC1-A series inverters. Before installation and operation please read these instructions in this manual thoroughly. For your safety, the product should only be installed, tested and adjusted by professional personnel. If you have any questions or problems, please contact our local agency. The information contained in this manual is subject to change without notice. CAUTION Indicates precautions that, if not avoided, could result in minor or moderate injury to personnel and damage to equipment. WARNING % ●Always turn off the input power supply before wiring. % ●Do not touch any inner part of the inverter when the charging lamp is still on shortly after the AC power is cut off. % ●Do not check signals while the inverter is running. % ●Do not attempt to modify or alter the inverter by yourself, doing so can result in electrical shock or injury or even explosion. 1. ●Be sure to ground the E terminal. 2. CAUTION % ●Do not perform voltage withstand tests on the inverter. % ●Never connect the AC main circuit power supply to output terminals U.V and W. % ●A CMOS IC is used in the control board. Handle the control board and CMOS IC carefully. The CMOS IC can be destroyed by static electricity if touched directly. % ●Installation, testing and maintenance must be performed by professional personnel. % ●The inverter should be discarded as industrial waste. Avoid burning. 1.1 Receiving Before unpacking please check the following: % ●Inspect the entire exterior of the inverter to see there are any scratches or other damage resulting from shipping. % ●Check if there is an inverter and an operation manual in the package as soon as you open the package. % ●Check the model on the nameplate on the side of the inverter to see if this is the right model you want. % ●Check if there is something wrong with the inner parts, wiring and circuit board. % ●Use a screwdriver or other tools to check for tightness. % ●Check if there is any other things in the machine. % ●Check if the operator buttons are all right. % ●Check if the optional device you ordered is contained in it. 1.2 Nameplate information MODEL: HC1A07D543B INPUT: 3 Ph 400V 50/60Hz OUTPUT : 3 Ph 400V 17.5A 7.5KW Freq- Range: 0.1~400Hz TECORP ELECTRONICS CO., LTD. 2.Safety precautions CAUTION 1●Check to be sure that the voltage of the main circuit AC power supply matches the rated voltage of the inverter. 2 CAUTION % ●E symbol is the ground terminal, Be sure to ground the ground terminal. 1●Do not Connect electromagnetic switches or contactors to the output circuits. 2to the inverter. The installation diagram like this is forbidden. % ●Do not connect contactor to the input circuits. The service life of the inverter can be much longer if you start or stop the inverter by pressing the buttons FOR or REV,especially in those frequently starting and stopp conditions. 2.2 In delivery of current WARNING % ●Do not remove connectors on the inverter when in delivery of current. % ●Always have the protective cover in place before delivery of current to avoid electrical shock. 2.3 In running WARNING 1●Never add or remove motor group while in running, the surge current it created will cause damage to the inverter, even burn-up of the main circuit. 2 WARNING % ●Never remove the front cover of the inverter while in running. % ●Do not come close to the machine when the fault restart function is used. If the alarm is cleared, the machine may start moving suddenly. 1●The function of the STOP button can only be available after setting. It is different from the emergency stop button. Please note. 2 CAUTION % ●Do not touch the heat sink, braking resistor, or Braking Resistor Unit. These can become very hot. % ●Be sure that the motor and machine is within the applicable ranges before starting operation. % ●Do not check the signals while the inverter is running. % ●Be careful when changing inverter settings. The inverter has been set to suitable for general using in factory. % ●Do consider the noise,vibration,and the speed limit of the motor and the mechanical devices when the inverter is running at or above the frequency of 50Hz. 1. 3. Standard Specifications 2. 3.1 Individual Specifications 3. 3.2 Common Specifications MODEL Input Voltage Power (KW) Driver Capacity (KVA) Output Current (A) Suitable Motor (KW) HC1A00D423B 1Φ/3Φ220V 0.4 1.0 2.5 0.4 HC1A0D7523B 1Φ/3Φ220V 0.75 2.0 5.0 0.75 HC1A01D523B 1Φ/3Φ220V 1.5 2.8 7.0 1.5 HC1A02D223B 1Φ/3Φ220V 2.2 4.0 10 2.2 HC1A0D7543B 3Φ400V 0.75 2.2 2.7 0.75 HC1A01D543B 3Φ400V 1.5 3.2 4.0 1.5 HC1A02D243B 3Φ400V 2.2 4.0 5.0 2.2 HC1A03D743B 3Φ400V 3.7 6.8 8.5 3.7 HC1A05D543B 3Φ400V 5.5 10 12.5 5.5 HC1A07D543B 3Φ400V 7.5 14 17.5 7.5 HC1A001143B 3Φ400V 11 19 24 11 HC1A001543B 3Φ400V 15 26 33 15 HC1A18D543B 3Φ400V 18.5 32 40 18.5 HC1A002243B 3Φ400V 22 37 47 22 HC1A003043B 3Φ400V 30 52 65 30 HC1A003743B 3Φ400V 37 64 80 37 HC1A004543B 3Φ400V 45 72 91 45 HC1A005543B 3Φ400V 55 84 110 55 HC1A007543B 3Φ400V 75 116 152 75 HC1A009043B 3Φ400V 90 134 176 90 HC1A011043B 3Φ400V 110 160 210 110 HC1A013243B 3Φ400V 132 193 253 132 HC1A016043B 3Φ400V 160 230 304 160 HC1A018543B 3Φ400V 185 260 340 185 HC1A020043B 3Φ400V 200 290 380 200 HC1A022043B 3Φ400V 220 325 426 220 HC1A025043B 3Φ400V 250 368 483 250 HC1A028043B 3Φ400V 280 412 540 280 MODEL Input Voltage Power (KW) Driver Capacity (KVA) Output Current (A) Suitable Motor (KW) HC1A030043B 3Φ400V 300 450 580 300 HC1A031543B 3Φ400V 315 461 605 315 HC1A037543B 3Φ400V 375 550 800 375 HC1A041543B 3Φ400V 415 610 880 415 HC1A045043B 3Φ400V 450 665 960 450 ITEM HC1-A Control Method SPWM Input Power Supply 400V Power Supply:340 VAC - 460VAC 220V Power Supply:180 VAC – 250 VAC Fre qu enc y Co ntr ol Frequency Range 0.10~400.00Hz Frequency Accuracy Digital:0.01%(-10~40℃) Analog:0.1% (25±10℃) Frequency Setting Resolution Digital:0.01Hz Analog:1% of Max Operating Frequency Output Resolution 0.01Hz Operator Setting Method Press←or ∧ or ∨ to set Analog Setting Method 0-5V / 0-10V 4-20mA / 0-20mA Other functions Frequency up/lower limit, start frequency, stopping frequency, three skip frequencies can be individually set. Ge ner al Co ntr ol Acceleration/Dec eleration time 0.1-6500s four selectable combinations of independent acceleration and deceleration setting. V/F Curve Set V/F curve at will. Torque Control Max Torque 10.0% Max Output Voltage. The starting torque can reach 150% at 1.0Hz Multi-function input terminals 6 multifunction input terminals for 8 multi- speed, easy PLC, 4 Accel/Decel time,UP/DOWN command, external emergency stop. ITEM HC1-A Communication Control RS485 Operating Temperature -10~40℃ Humidity 0-95% relative humidity Vibration 0.5G or lower Pro tec tio n Fu nct ion Instantaneous over current Approx. 200% rated current. Over Load Inverter:150% 1 minute. Motor Overload Protection Electronic thermal overload relay. Over Voltage 23 series: DC bus over 400Vdc 43 series: DC bus over 800Vdc Under Voltage 23 series: DC bus voltage drop 200Vdc 43 series: DC bus voltage drop 400Vdc Momentary Power Loss 0-2 seconds: The inverter can be restarted by speed search. Heat Sink over heat Protected by thermistor Multi-function output terminals 5 multifunction output terminals for the displaying and warning of on-running, zero speed, counting and external fault information. Other functions AVR, Decelerating stop or free-stop, DC brake, auto restart tracking, easy PLC auto energy saving, adjustable carrier Frequency (Max 20KHz) etc. Digital operator monitor Frequency command,output frequency, speed output current, output voltage. DC bus voltage and rotation direction. 4.Storage &Installation 4.1 Storage This product must be stored in its package box before installation.Pay more attention to the followings when in storage. % ●It must be stored in a dry place without rubbish or dust. % ●The suitable temperature for storage is between -20℃and +65℃. % ●The relative humidity required is 0-95%,no condensation. % ●There is no corrosive gas or liquid. % ●It’s better to lay the inverter in its original package on a shelf. 4.2 Location Note: The working conditions of the inverter will affect its service life,please install the inverter under the following conditions. % ●Ambient operating temperature -10℃ to 40℃. % ●IP rating: IP 20 for all models. % ●Protected from rain moisture. % ●Shielded from direct sunshine. % ●Free from metallic particles and corrosive gas. % ●Free from excessive vibration. 4.3 Positioning % ●There must be enough space left around the inverter for easy maintenance and effective ventilation.See Diagram 1. % ●The inverter must be installed with heat sink ribs oriented vertically for effective ventilation % ●If there is any instability when installing the inverter, please put a flat board under the inverter bottom base and install again. If the inverter is installed on a loose surface, stress may cause damage in main circuit. % ●The inverter should be installed on non-combustible materials, such as iron plates. % ●If several inverters are installed together in one cabinet, please add heat dissipation plates and provide enough space between the inverters. See Diagram 2. Diagram 1 Diagram 2 1. 5. Wiring 2. 5.1 Main circuit schematic diagram ①Power supply: Verify that the inverter rated voltage coincides with AC power supply voltage. ②No fuse breaker or ground fault interrupter. ③Magnetic contactor Note: Don’t use the magnetic contactor as the power supply on/off button for the inverter. ④AC reactor for power factor improvement. ⑤TECORP Inverter (HC1-A series) ⑥3 phases squirrel cage induction motor. 5.2 Terminals 5.2.1 Main Circuit Terminals Arrangement HC1A00D423B-HC1A02D223B HC1A0D7543B-HC1A03D743B HC1A05D543B-HC1A07D543B E R S T U V W P1 P PR HC1A00D423B-HC1A01D523B HC1A0D7543B-HC1A02D243B
